Machinery Directive 2006/42/EC: The Complete Technical Compliance Guide

What Engineers and Product Managers Need to Know Before CE Marking Machinery

The Machinery Directive 2006/42/EC remains one of the most technically demanding frameworks in EU product legislation. Covering everything from industrial robots to domestic lawnmowers, it imposes rigorous Essential Health and Safety Requirements (EHSRs) that manufacturers must systematically satisfy before a product can bear the CE mark and enter the European Economic Area.

This guide is written for engineers, technical managers, and compliance professionals who need more than a surface-level overview. You will find precise directive references, applicable harmonised standards, common documentation failures, and a clear procedural pathway from risk assessment to Declaration of Conformity.

---

Scope: What Does 2006/42/EC Actually Cover?

The directive applies to machinery, interchangeable equipment, safety components, lifting accessories, chains, ropes and webbing, removable mechanical transmission devices, and partly completed machinery. Article 2 provides the legal definitions, and getting scope classification right is a prerequisite for everything that follows.

Machinery is broadly defined as an assembly fitted with or intended to be fitted with a drive system other than directly applied human or animal effort, consisting of linked parts or components, at least one of which moves. This captures the vast majority of powered industrial and consumer equipment.

Notable exclusions under Article 1(2) include:

• Seagoing vessels and mobile offshore units
• Agricultural and forestry tractors covered by Directive 2003/37/EC (now Regulation (EU) 167/2013)
• Military and police equipment
• Electrical and electronic products in the low-voltage range covered exclusively by Directive 2014/35/EU (Low Voltage Directive), where the electrical hazard is the only hazard
• Pressure vessels covered by 2014/68/EU

Misidentifying scope is among the costliest early-stage errors. A product incorrectly excluded from 2006/42/EC may reach the market without the risk assessment and technical documentation the directive mandates.

---

The Essential Health and Safety Requirements (EHSRs)

Annex I of the directive contains the EHSRs — the substantive technical and safety obligations. There are over 160 individual requirements structured across six sections:

• Section 1: General principles (design for safety, materials, lighting, maintenance)
• Section 2: Controls — control systems, stopping, speed, operator position
• Section 3: Protection against mechanical hazards (stability, fracture risk, sharp edges, rotating parts)
• Section 4: Required characteristics of guards and protective devices
• Section 5: Hazards from other energy sources (electrical, hydraulic, pneumatic, thermal)
• Section 6: Maintenance, information and markings

Each ESHR is performance-based, not prescriptive. The directive tells you what outcome to achieve, not exactly how. This is where harmonised standards become critical — they provide the presumption of conformity bridge between the ESHR and a measurable technical specification.

---

Harmonised Standards: Your Practical Conformity Pathway

Harmonised standards under the Machinery Directive are published in the Official Journal of the European Union (OJEU). Compliance with a harmonised standard creates a rebuttable presumption of conformity with the EHSRs it covers. They are organised in a three-tier structure:

Type A Standards (Basic Safety Concepts)

These apply to all machinery. The most important is EN ISO 12100:2010 — Safety of machinery: General principles for design, risk assessment and risk reduction. This standard defines the iterative risk assessment methodology that underpins all ESHR compliance work.

Type B Standards (Generic Safety Aspects)

These cover specific hazards or safety measures applicable across multiple machine types. Key examples include:

• EN ISO 13849-1:2015 — Safety-related parts of control systems (performance levels PLa–PLe)
• EN 62061:2021 (IEC 62061) — Functional safety for safety-related electrical control systems (SIL 1–3)
• EN ISO 13857:2019 — Safety distances to prevent reach to hazard zones
• EN ISO 14120:2015 — Guards: general requirements
• EN ISO 13855:2010 — Positioning of safeguards with respect to approach speeds

Type C Standards (Machine-Specific)

These provide detailed requirements for particular machine categories and take precedence over Type B standards where conflicts arise. Examples include EN 692 (mechanical presses), EN ISO 10218 (industrial robots), and EN 13241 (industrial doors and gates).

Where no harmonised standard exists or only partially covers the hazards identified, manufacturers must use alternative technical specifications and document their rationale thoroughly in the technical file.

---

Conformity Assessment Procedures Under Article 12

The directive establishes several conformity assessment routes depending on machinery type.

Annex VIII — Internal Production Control (Most Common Route)

For most machinery not listed in Annex IV, the manufacturer conducts their own conformity assessment, compiles the technical file, and issues the EC Declaration of Conformity without third-party involvement. This is the default route.

Annex IV — Machinery Requiring Special Attention

Annex IV lists 23 categories of high-risk machinery, including:

• Circular saws for working wood
• Presses for cold working of metals
• Injection and compression plastics moulding machinery
• Underground working machinery (locos, hydraulic powered roof supports)
• Guards and safety devices for Annex IV machinery

For Annex IV machinery, the manufacturer has three options under Article 12(3) and 12(4):

1. Apply harmonised standards covering all relevant EHSRs → self-certify via Annex VIII
2. Have a Notified Body examine the technical file (Annex IX EC Type-examination)
3. Submit the technical file to a Notified Body for full quality assurance (Annex X)

Partly Completed Machinery — Annex II, Section B

This is a frequently mishandled category. Partly completed machinery (e.g., a gearbox, conveyor subassembly, or robot without a controller configured for a specific application) cannot bear the CE mark. It requires:

• An Incorporation Declaration (not a Declaration of Conformity)
• An Assembly Instructions document explaining how it must be integrated
• A technical file demonstrating EHSRs it satisfies and those it deliberately does not satisfy

The integrator who assembles partly completed machinery into a final assembly then takes on the obligation to assess and CE mark the complete machine.

---

Step-by-Step Compliance Process

Step 1: Determine Applicability and Scope

Confirm the product is in scope, identify whether it is machinery, partly completed machinery, or a safety component, and check Annex IV against your machine type.

Step 2: Conduct Risk Assessment Per EN ISO 12100

This is the foundation of all subsequent work. The standard defines a three-step method: inherently safe design → safeguarding and protective measures → information for use. Document all hazards identified, the risk estimation, risk evaluation, and residual risks systematically.

Step 3: Identify Applicable EHSRs and Harmonised Standards

Work through Annex I systematically. For each relevant ESHR, identify whether a harmonised standard covers it, and if so, which. This mapping must be explicit in your technical documentation.

Step 4: Design and Verify

Implement design measures, guards, safety-related control functions (assessed per EN ISO 13849-1 or EN 62061), and ergonomic features. Perform or commission testing against applicable harmonised standards.

Step 5: Compile the Technical File (Annex VII, Part A)

The technical file must contain at minimum:

• A general description of the machinery
• Overall drawings and control circuit diagrams
• Full detailed drawings with calculations, test results, certificates
• The risk assessment documentation
• A list of EHSRs applied, standards used, and other technical specifications
• Technical reports from tests carried out
• A copy of the instructions for use

This file must be available to competent national authorities for at least 10 years from the date of last manufacture.

Step 6: Prepare Instructions for Use (Annex I, Section 1.7.4)

Instructions must be provided in the official EU language(s) of the country of destination. They must include intended use, misuse warnings, assembly, installation, commissioning, operating, adjustment, maintenance, and decommissioning information.

Step 7: Issue the EC Declaration of Conformity (Annex II, Section A)

The Declaration must include the manufacturer’s name and address, machinery description, applicable directive(s) and standards, signatory details, place and date of issue, and the authorised representative’s details if applicable.

Step 8: Affix the CE Mark

CE marking must comply with the proportionality requirements of Annex III and follow the general rules in Regulation (EC) 765/2008. The CE mark must be visible, legible, and indelible.

---

Common Mistakes That Lead to Market Surveillance Action

Inadequate risk assessment documentation. Completing a risk assessment is not enough — it must be traceable. Authorities routinely find files listing hazards without documented risk estimation logic or evidence that residual risks were re-evaluated after protective measures were applied.

Misapplying EN ISO 13849-1. Performance Level calculations that omit diagnostic coverage (DC), common cause failure (CCF) analysis, or mean time to dangerous failure (MTTFd) data for purchased components create false confidence in control system integrity. Category B is not the same as Category 1 — understand the architectural constraints.

Treating instructions as an afterthought. Section 1.7.4 of Annex I is exhaustive. Missing information about foreseeable misuse, residual risks, or noise and vibration emission data are common non-conformances found during market surveillance.

Partly completed machinery incorrectly CE marked. A drive unit sold as a standalone product bearing a CE mark when it cannot function safely without further integration misleads downstream users and creates liability exposure for the original manufacturer.

Ignoring the 2-year review cycle on harmonised standards. Standards are revised. EN ISO 13849-1:2015 superseded the 2006 version, and transition periods create windows where either version may be used. But relying on a withdrawn standard post-transition removes the presumption of conformity.

Over-reliance on generic declarations. Some manufacturers issue declarations referencing broad swathes of directives and standards without confirming applicability. A declaration referencing the Pressure Equipment Directive for a machine with no pressurised elements is a red flag in any audit.

---

The Machinery Regulation (EU) 2023/1230 — What’s Coming

The Machinery Regulation (EU) 2023/1230 was published in the OJEU on 29 June 2023 and will repeal and replace 2006/42/EC from 14 January 2027. Unlike a directive, it will apply directly without national transposition.

Key changes include expanded scope for software and digital safety functions, updated provisions for AI-enabled machinery, clearer rules for cybersecurity as a safety matter, and strengthened market surveillance powers. Organisations with long product development cycles should already be mapping their designs against the new regulation’s requirements.

---

Frequently Asked Questions

Q: Can I CE mark machinery designed for export outside the EU?
Technically yes, but the CE mark is an EU market access tool. Applying it to products exclusively destined for third-country markets creates confusion about applicable standards and could constitute misuse. Exporters should verify whether the destination country accepts or requires CE marking.

Q: What is the role of a Notified Body for non-Annex IV machinery?
There is no mandatory Notified Body involvement for standard machinery. However, manufacturers may voluntarily engage a Notified Body to review technical documentation, which can be valuable for liability management or where novel technology means no harmonised standard exists.

Q: Does software require separate assessment under 2006/42/EC?
Yes. Safety-related software embedded in control systems must be assessed as part of the functional safety evaluation under EN ISO 13849-1 or EN 62061. The directive does not exempt software from the ESHR obligations, and software failures must be addressed in the risk assessment.

Q: How does 2006/42/EC interact with the Low Voltage Directive 2014/35/EU?
For machinery in scope of 2006/42/EC that has electrical hazards, the Machinery Directive takes precedence. Article 3 of 2006/42/EC establishes that where specific EHSRs are more precisely defined in other EU legislation, those provisions apply for those hazards — but the CE marking process is conducted under 2006/42/EC, not 2014/35/EU, for in-scope machinery.

Q: What constitutes “substantial modification” triggering a new conformity assessment?
There is no bright-line definition in the directive, but the European Commission’s guidance document (MACHINERY — Application Guide for Directive 2006/42/EC) advises that any modification affecting safety-related design features, guard systems, control logic, or the original risk assessment assumptions should be re-evaluated. If the modification creates new hazards or increases existing risks, a new conformity assessment is required. Post-modification responsibility rests with whoever made the change.

---

Conclusion

Machinery Directive 2006/42/EC compliance is not a documentation exercise — it is a design and engineering discipline. The directive’s performance-based requirements demand genuine technical engagement: rigorous hazard identification, evidence-based risk reduction, properly verified control system integrity, and complete, accurate documentation. Market surveillance authorities across the EU are active, and the consequences of non-compliance — forced withdrawal, injunctions, and liability exposure — are material.

With the Machinery Regulation (EU) 2023/1230 coming into force in January 2027, now is the right time to build compliance competence that will carry forward into the new framework.

---
